| Conductor surface |
Bare |
| Awg size |
23 |
| Conductor category |
Class 1 = solid |
| Total number of cores |
8 |
| Stranding element |
Pairs |
| Specification core insulation |
PE |
| Core identification |
Colour |
| Overall screening |
None |
| Conductor screening |
Foil |
| Outer sheath material |
Copolymer, thermoplastic (LS0H) |
| Outer sheath colour |
Ice blue |
| Reaction-to-fire class according to en 13501-6 |
Dca |
| Smoke development class according to en 13501-6 |
s2 |
| Euro class flaming droplets/particles according to en 13501-6 |
d1 |
| Euro class acidity according to en 13501-6 |
a1 |
| Halogen free (acc. en 60754-1/2) |
yes |
| Flame retardant |
In accordance with EN 60332-1-2 and EN 50399 |
| Low smoke (acc. bs en 61034-2) |
yes |
| Outer diameter approx. |
7.2 mm |
| Installation temperature range |
0...60 °C |
| Operating temperature range |
-20...60 °C |
| Category |
6A (IEC) |
| Nvp value |
75 % |
